Page 33 - vG_2024Catalogue_sm

32 CROSS GUARD 33

20 OZ. PATTERNED SCROLL CARPET TILE

®
INDOOR
Where two weathered avenues converge and
offer a pathway forward lies the vision behind
Cross Guard. Intersecting lines layered over a
mottled base of neutral earth tones softly reflect
the symmetry and imperfect beauty of urban
connectivity.
1. 3.
SPECIFICATIONS

Construction Patterned Scroll
Standard Backing Nexus® Modular
Dye Method Solution Dyed
Fiber Type TeraPlex® SD PET
Face Weight 20 oz./sy (678 grams/m2)
Pile Density 10141 oz./y3 (376.03 kg/m3)
2.
Pattern Repeat N/A
Gauge 1/12 (4.72 rows/cm)
Total Thickness (nominal average) 0.245 inches 1. Dapple Grey 3. Steel
Standard Size 24” x 24” approx. (60.96cm x 60.96cm) 2. Slate
Special Treatments ProTex® Soil Release
Optional Backings Nexus® Cushion
Standard Adhesive Commercial on Premium Modular & LVT Adhesive
Optional Adhesive Tile Tabs

ENVIRONMENTAL SPECIFICATIONS & TESTS Carpet Tile Goods | Cross Guard Tile | Zones 2-3

SCAS / NSF 140 Gold Certified
Total Recycled Content 40.71%
Flooring Radiant Panel Class 1
Smoke Density Less than 450.0 flaming (ASTM E 662)
Static Test Less than 3.0 kv (AATCC-134)
ADA Compliance Compliant For Accessible Routes
Pill Test Yes
Light fastness Yes

1+706 602 4186 | www.vangelder-inc.com
